Vibration Exciter

APS Dynamics Inc. designs and manufactures mainly Long Stroke Vibration Exciters for the low frequency range. The ELECTRO-SEIS® shakers are available in two different configurations – ball bearing type shakers and air bearing type shakers.



Ball Bearing

The ball bearing shakers are used primarily for modal test excitation or environmental test applications in the low frequency range < 200 Hz. Although these shakers have a long stroke (158 mm) they are still portable. Thus APS ELECTRO-SEIS® shaker are ideal tools for testing of bridges, buildings or other objects outside a laboratory.

Air Bearing

For sensor calibration applications or testing applications that require a smooth motion of the exciter, the APS Shakers feature air bearing armature guidance for exceptionally clean waveforms with wide dynamic range and very low cross-axis motion.

Filter Products expand_more expand_less

Reset Filters

Measurand

Long Stroke Shaker_APS 113-AB

APS 113-AB

APS 113-AB

Air-bearing ELECTRO-SEIS® Long Stroke vibration exciter, especially developed for the calibration and testing for low frequency sensors and sensor charcterization.

Air Bearing vibration exciter

chevron_right

Long Stroke Shaker APS 129

APS 129

APS 129

Air-bearing ELECTRO-SEIS® Long Stroke Vibration Exciter with mounting table for high payloads up to 23 kg. Especially developed for the calibration and testing of big and heavy low frequency sensors as well as for sensor characterization (e.g. geophones or heavy seismic sensors).

Air-bearing Long Stroke Vibration Exciter

chevron_right

Long Stroke Shaker_APS 500

APS 500

APS 500

Air-bearing ELECTRO-SEIS® Long Stroke vibration exciter with mounting table for payloads up to 3 kg. Especially developed for the calibration and testing of compact low frequency sensors and for sensor characterization at higher acceleration.

Air-bearing Long Stroke vibration exciter

chevron_right

APS 600

APS 600

Air-bearing ELECTRO-SEIS® Long Stroke vibration exciter with mounting table for very high payloads. Especially developed for the calibration and testing of geophones and heavy seismic sensors.

Air-bearing Long Stroke vibration exciter

chevron_right

APS 113

APS 113

Ball-bearing ELECTRO-SEIS® Long-Stroke vibration exciter specifically designed to be used alone or in arrays for modal excitation of complex structures, particularly when low frequencies are required. Different operating modes with reaction masses, fixing points or auxiliary table kits multiply the application possibilities.

Ball-bearing Long-Stroke vibration exciter

chevron_right

APS 400 with calibration table in horizontal and vertical alignment

APS 400

APS 400

ELECTRO-SEIS® Long-Stroke vibration exciter with 445 N max. force that is suitable for excitation of large structures such as ceilings or bridges.

Ball-bearing Long-Stroke vibration exciter

chevron_right

Long Stroke Shaker APS 420

APS 420

APS 420

The strongest ELECTRO-SEIS® Long-Stroke vibration exciter to date is used for vibration tests of airplanes and other large structures. With a maximum force of 900 N and up to 150 mm stroke the shaker unlocks a new performance level.

Ball-bearing Long-Stroke vibration exciter

chevron_right

Horizontal Reaction Mass System APS 4001

APS 4001

APS 4001

The APS 4001 - Horizontal Reaction Mass System provides a means of extending the rated force output for the APS 400 Shaker to frequencies as low as 0.5 Hz.

Horizontal Reaction Mass System

chevron_right
